Sale!

AMD Ryzen 5 7600X R5 7600X CPU + ASUS TUF GAMING B650M PLUS WIFI Motherboard Suit DDR5 Socket AM5 All new but without cooler

AMD Ryzen 5 7600X R5 7600X CPU + ASUS TUF GAMING B650M PLUS WIFI Motherboard Suit DDR5 Socket AM5 All new but without cooler - Image 2

AMD Ryzen 5 7600X R5 7600X CPU + ASUS TUF GAMING B650M PLUS WIFI Motherboard Suit DDR5 Socket AM5 All new but without cooler - Image 3

AMD Ryzen 5 7600X R5 7600X CPU + ASUS TUF GAMING B650M PLUS WIFI Motherboard Suit DDR5 Socket AM5 All new but without cooler - Image 4

AMD Ryzen 5 7600X R5 7600X CPU + ASUS TUF GAMING B650M PLUS WIFI Motherboard Suit DDR5 Socket AM5 All new but without cooler

Name: AMD Ryzen 5 7600X R5 7600X CPU + ASUS TUF GAMING B650M PLUS WIFI Motherboard Suit DDR5 Socket AM5 All new but without cooler
SKU: 1005004846007688
Availability: InStock

The battery in the motherboard picture will be removed before shipment, because the use of battery is prohibited in China Post and CustomsThis product is brand new and comes with a one-year warranty period Preview General information Type CPU / Microprocessor Market segment Desktop Family AMD Ryzen 5 Model number 7600X CPU part numbers 100-000000593 is […]

Bundle

Clear

SKU: 1005004846007688

Category: Motherboards

Description

Preview

General information
Type	CPU / Microprocessor
Market segment	Desktop
Family	AMD Ryzen 5
Model number	7600X
CPU part numbers	100-000000593 is an OEM/tray microprocessor 100-100000593WOF is a boxed microprocessor without fan and heatsink
Frequency	4.7 GHz / 4700 MHz
Maximum turbo frequency	5.3 GHz / 5300 MHz
Bus speed	32 GT/s PCI Express interface [1]
Package	1718-pin lidded Land Grid Array (LGA)
Socket	Socket AM5
Introduction date	August 29, 2022 (announcement) September 27, 2022 (availability)
Price at introduction	$299
Architecture / Microarchitecture
Instruction set	x86
Microarchitecture	Zen 4
Processor core	Raphael
Manufacturing process	TSMC 0.005 micron FinFET process (CPU die) TSMC 0.006 micron FinFET process (I/O die)
Die	71mm2 (CPU die) 122mm2 (I/O die)
Data width	64 bit
The number of CPU cores	6
The number of threads	12
Floating Point Unit	Integrated
Level 1 cache size	6 x 32 KB instruction caches 6 x 32 KB data caches
Level 2 cache size	6 x 1 MB caches
Level 3 cache size	32 MB shared cache
Physical memory	128 GB
Multiprocessing	Uniprocessor
Extensions & Technologies	MMX instructions Extensions to MMX SSE / Streaming SIMD Extensions SSE2 / Streaming SIMD Extensions 2 SSE3 / Streaming SIMD Extensions 3 SSSE3 / Supplemental Streaming SIMD Extensions 3 SSE4 / SSE4.1 + SSE4.2 / Streaming SIMD Extensions 4 SSE4a AES / Advanced Encryption Standard instructions AVX / Advanced Vector Extensions AVX2 / Advanced Vector Extensions 2.0 AVX-512 / Advanced Vector Extensions 512 BMI / BMI1 + BMI2 / Bit Manipulation instructions F16C / 16-bit Floating-Point conversion instructions FMA3 / 3-operand Fused Multiply-Add instructions SHA / Secure Hash Algorithm extensions AMD64 / AMD 64-bit technology SMT / Simultaneous MultiThreading AMD-V / AMD Virtualization technology Precision Boost 2
Security Features	EVP / Enhanced Virus Protection
Low power features	Pure Power [1]
Integrated peripherals / components
Display controller	4 displays
Integrated graphics	GPU Type: Radeon Microarchitecture: RDNA 2 Shader cores: 128 Base frequency (MHz): 400 Maximum frequency (MHz): 2200
Memory controller	Memory channels (total): 2 Supported memory: DDR5-5200 ECC supported: Yes
Other peripherals	PCI Express 5.0 interface (24 lanes [1])
Supported interfaces	USB-C interface USB 3.2 Gen 2 (4 ports) USB 2.0 (1 port)
Electrical / Thermal parameters
Maximum operating temperature	95°C
Thermal Design Power	105 Watt
Notes on AMD Ryzen 5 7600X
The processor has unlocked clock multiplier The CPU package contains 1 CPU die and 1 I/O die [1] – Information is not confirmed

Additional information

RAID Supported	no
Processor compatibility	AMD Ryzen 7000 Series-R3,AMD Ryzen 7000 Series-R5,AMD Ryzen 7000 Series-R7,AMD Ryzen 7000 Series-R9
Usage Scenario	others
Special Function	none
Back I/O Ports	1x RJ45
Support USB Type	USB 2.0,USB 3.2 Gen1,USB 3.2 Gen2
Onboard LAN	1x RJ45
Audio Channels	7.1
Supports M.2 SSD	2242,2280,2260
Number of M.2	2
Number of SATA Ports	4
Storage Interface Type	SATA,M.2 (NVMe)
Number of PCI	2
Number of PCIe x 4	1
Number of PCIe x 16	2
PCI – E standards	PCI – E 4.0
Number Of Memory Slots	4
Support Memory Type	DDR5
Quality Certification	FCC
Memory channel	Double
Package	Yes
Maximum Ram Capacity	128 GB
Form Factor	Micro-ATX
Chipset Manufacturer	AMD
With CPU	No
Chipset	AMD B650
Application	Desktop
Socket Type	Socket AM5
Brand Name	Asus
Origin	Mainland China
CPU Model	Ryzen 5 7600X / R5 7600X
CPU Warranty	One year warranty
Motherboard Warranty	One year warranty
CPU Condition	New
Motherboard Condition	New
Cooler	None . Without cooler
Motherboard Dimension	24.4 cm x 24.4 cm
Memory slot	Supports 4 X 48G memory at the most
Motherboard Battery	None
Integrated Graphics	Yes
Bundle	Motherboard+CPU
